Hastelloy round bar
Table of content

We are most trustworthy hastelloy rod manufacturer in India

Consider things before purchase Hastelloy rod

Consider things before purchase Hastelloy rod

As supplier of cut-to-size ASTM B574 hastelloy flat bar and and hex bar in Mumbai, we focuses on the stock and prompt delivery at lowest price

Hastelloy bar price
Grade Per unit in INR Price in USD
Hastelloy C276 3000 Rs $36.08
Hastelloy C-22 2600 Rs $31.27

Fully accredited stockist of ASME SB574 hastelloy alloy square bar and shaft with size ranging from 0.125 to 12 inches with various delivery condition

Hastelloy round bar specification
Diameter Condition Length
1/2" to 10" cold drawn, annealed, turned etc. upto 24" or custom cut length
Specification Grades Form
ASTM B574 | ASME SB574 Hastelloy C276, C22, B2, B3, X Round, Hex, Square, Rectangular etc.
Exporter of Hastelloy bright and rectangular bar, Get chance to purchase different shapes online at reduce costs.
Most frequent types of hastelloy rod
Hastelloy rod

Hastelloy rod

ASTM B574 hastelloy flat bar

ASTM B574 hastelloy flat bar

Hastelloy hex bar

Hastelloy hex bar

Hastelloy alloy square bar

Hastelloy alloy square bar

ASME SB574 hastelloy shaft

ASME SB574 hastelloy shaft

Hastelloy rectangular bar

Hastelloy rectangular bar

Grade chart of Hastelloy hex bar
Material Grades
Hastelloy alloy Alloy C276
Alloy C22
Alloy B2
Alloy B3
Alloy X
Hastelloy bar HS Code
Description HS Code
Hastelloy Round Bar 75051220
Hastelloy round bar weight calculator

Alloy:

Shape:

Number of Pieces:

Enter size information:

Calculated Weight:

Point to remember before selecting Hastelloy bar supplier

Point to remember before selecting Hastelloy bar supplier

As one of the top hastelloy round bar dealer, we can help with all of your hastelloy alloy cold drawn, hot rolled, annealed, forged bar supply needs. You can view it's various properties here
Hastelloy hex bar equivalent
STANDARD UNS BS WERKSTOFF NR. JIS GOST EN OR
Hastelloy C22 N06022 - 2.4602 NW 6022 - NiCr21Mo14W -
Hastelloy C276 N10276 - 2.4819 NW 0276 ХН65МВУ NiMo16Cr15W ЭП760
Hastelloy B2 N10665 - 2.4617 - - - -
Hastelloy flat bar mechanical properties
  Elongation Density Melting Point Tensile Strength Yield Strength (0.2%Offset)
C276 40% 1370 °C (2500 °F) Psi – 1,15,000 , MPa – 790 8.89 G/Cm33 Psi – 52,000 , MPa – 355
C22 45 % 1399 °C (2550 °F) Psi – 1,00,000 , MPa – 690 8.69 G/Cm3 Psi – 45000 , MPa – 310
B3 40% 1370 °C (2550 °F) Psi – 1,15,000 , MPa –760 9.2 G/Cm3 Psi – 52,000 , MPa – 350
B2 40% 1370 °C (2550 °F) Psi – 1,15,000 , MPa –760 9.2 G/Cm3 Psi – 52,000 , MPa – 350
Hybrid BC1 40% 1343 - 1443°C 725 8.83 G/Cm³ 310
C4 55% 1350-1400 °C 783 8.64 G/Cm3 365
X 35% 1355°C 655 MPa 8.22 G/Cm³ 240 MPa
Hastelloy alloy square bar chemical properties
Grade UNS Cr Mo S≤ Si≤ Fe C≤ Co≤ Mn≤ P≤
C276 N10276 14.5-16.5 15.0-17.0 0.03 0.08 4.0-7.0 0.01 2.5 1.0 0.04
C22 N06022 20.0-22.5 12.5-14.5 0.02 0.08 3.0-6.0 0.015 2.5 0.5 0.02
B3 N10675 1.0-3.0 27.0-32.0 0.01 0.10 1.0-3.0 0.01 3.0 3.0 0.03
B2 N10665 1.0max 26.0-30.0 0.03 0.10 2.0max 0.02 1.0 1.0 0.04
X N06002 20.5-23.0 8.0-10.0 0.03 1.0 17.0-20.0 0.05-0.15 0.5-2.5 1.0 0.04
C2000 N06200 22.0-24.0 15.0-17.0 0.01 0.08 3.0max 0.01 2.0 0.5 0.025
Available size of Hastelloy bar
Angle bar Size: 3*20*20mm to 12*100*100mm
Round bar Diameter: 3 to 800mm
Flat bar Thickness: 2 to 100mm
Width: 10 to 500mm
Square bar Size: 4*4 to 100*100mm
Hexagonal bar Size: 2 to 100mm
Hastelloy rod tolerances
Section/Shape variation Permitted diameter, Size or width across flats
millimeter millimeter
Round + 0 to - 00.070
+ 0 to - 00.085
+ 0 to - 00.100
+ 0 to - 00.120
+ 0 to - 00.140
≥6 ≦ 18
> 18 ≦ 30
> 30 ≦ 50
> 50 ≦ 80
> 80 ≦ 100
Square and
hexagon
+ 0 to - 00.090
+ 0 to - 00.110
+ 0 to - 00.130
+ 0 to - 00.160
+ 0 to - 00.250
≥ 6 ≦ 18
> 18 ≦ 30
> 30 ≦ 50
> 50 ≦ 80
> 80 ≦ 105
Flat (thickness) + 0 to - 00.110
+ 0 to - 00.130
+ 0 to - 00.250
+ 0 to - 00.350
< 18
> 18 ≦ 30
> 30 ≦ 50
> 50 ≦ 80
Flat (width) + 0 to - 00.110
+ 0 to - 00.130
+ 0 to - 00.160
+ 0 to - 00.190
+ 0 to - 00.220
+ 0 to - 00.350
+ 0 to - 1.00
+ 1.00 to - 1.00
< 18
> 18 ≦ 30
> 30 ≦ 50
> 50 ≦ 80
> 80 ≦ 100
> 100 ≦ 130
> 130 ≦ 160
> 160 ≦ 320
Processing of ASME SA574 Hastelloy shaft
  • Heat Treatment
  • Machining
  • Hot Working
  • Heat Resistance
  • Welding
  • Cold Working
  • Fabrication
Hastelloy rectangular bar condition
ANN Annealed
H&T Hardened and tempered.
PH Precipitation hardened.
Size range of Hastelloy bright bar
Metric Japanese US Bar Canadian/ASTM
Diam. (mm) Bar Size Diameter (mm) Bar Size Diam. (Inch) Bar Size Diameter (mm2) Bar Size
6 6 13 13 0.500 #4 300 20M
5 5 6 6 0.250 #2 100 10M
7 7 16 16 0.625 #5 500 25M
5.5 5.5 10 10 0.375 #3 200 15M
8 8 19 19 0.750 #6 700 30M
10 10 25 25 1.000 #8 1500 45M
9 9 22 22 0.875 #7 1000 35M
50 50
11 11 29 29 1.125 #9 2500 55M
14 14 35 35 1.375 #11
12 12 32 32 1.250 #10
16 16 38 38 1.500 #12
20 20 44 44 1.750 #14
22 22 48 48 1.875 #15
18 18 41 41 1.625 #13
28 28 57 57 2.250 #18
25 25 51 51 2.000 #16
32 32
40 40
36 36
44 44
Application of Hastelloy steel round bar
  • Heavy engineering Industries
  • for manufacturing bearings, gear
  • Railway engines and coaches
  • used for Automobile Industries
  • used for Electric pumps / motors
  • manufacturing conveyor shafts
Hastelloy flat bar sizes
Flat bar – metric sizes and weights
Flat Size Standard Length (metres) KG’s per Metre Colour Code
13 x 3 6.0 0.31 Blue
10 x 3 6.0 0.24 Blue
13 x 5 6.0 0.46 Orange
16 x 5 6.0 0.64 Orange
16 x 3 6.0 0.38 Blue
16 x 8 6.0 1.03 Red
20 x 5 6.0 0.81 Orange
20 x 3 6.0 0.48 Blue
20 x 6 6.0 0.97 White
25 x 3 6.0 0.60 Blue
20 x 10 6.0 1.61 Yellow
25 x 5 6.0 1.01 Orange
25 x 8 6.0 1.61 Red
25 x 6 6.0 1.21 White
25 x 10 6.0 2.01 Yellow
32 x 3 6.0 0.77 Blue
25 x 12 6.0 2.41 Pink
32 x 6 6.0 1.55 White
32 x 5 6.0 1.29 Orange
32 x 8 6.0 2.06 Red
32 x 12 6.0 3.09 Pink
40 x 3 6.0 0.97 Blue
32 x 10 6.0 2.58 Yellow
40 x 5 6.0 1.61 Orange
Test certificates of Hastelloy cold drawn bar
  • 100% Radiography Test Report
  • Raw Materials Certificate
  • Third Party Inspection Report
  • EN 10204/3.1B
Hastelloy hex bar sizes
Wt per Ft Size in Inches Wt per 12′
0.180 1/4″ 2.160
0.104 3/16″ 1.248
0.290 5/16″ 3.480
0.104 3/16″ 1.248
0.560 7/16″ 6.72
0.625 3/8″ 4.920
0.740 1/2″ 8.880
1.150 5/8″ 13.80
0.930 9/16″ 11.16
1.660 3/4″ 19.92
1.390 11/16″ 16.68
1.950 13/16″ 23.40
2.625 15/16″ 31.20
2.300 7/8″ 27.60
2.90 1″ 34.80
3.700 1-1/8″ 44.40
3.30 1-1/16″ 39.60
4.625 1-1/4″ 55.20
5.625 1-3/8″ 67.20
5.100 1-5/16″ 61.20
6.100 1-7/16″ 73.20
7.800 1-5/8″ 93.60
18.42 2-1/2″ 221.04
6.625 1-1/2″ 79.20
9.030 1-3/4″ 108.36
11.80 2″ 141.60
10.400 1-7/8″ 124.80
16.920 2-3/8″ 203.04
14.920 2-1/4″ 179.04
26.53 3″ 318.36
Testing of Hastelloy alloy rod

testing of hastelloy alloy rod

  • PMI Testing
  • Hardness Test
  • Mechanical Testing
  • Chemical Analysis
  • Micro and MacroTest
  • Flattening Test
Weight chart of ASTM B574 Hastelloy bar
Size kilogram / Foot kilogram / Meter Size kilogram / Foot kilogram / Meter Size kilogram / Foot kilogram / Meter
1/" 0.019 0.062 3-1/4" 12.800 41.996 22mm 0.908 2.979
3mm 0.017 0.055 3" 10.900 35.762 20mm 0.753 2.470
5/32" 0.029 0.095 3-1/2" 14.850 48.772 7/8" 0.926 3.038
5mm 0.047 0.154 4-1/4" 21.908 72.249 1" 1.210 3.970
3/16" 0.043 0.141 4" 19.306 63.340 25mm 1.180 3.871
4mm 0.030 0.098 3-3/4" 17.001 55.780 24mm 1.080 3.543
6mm 0.068 0.223 4-3/4" 27.366 90.249 27mm 1.368 4.490
7/32" 0.058 0.190 4-1/2" 24.4487 80.340 26mm 1.271 4.170
7mm 0.091 0.298 5-1/2" 36.690 121.000 30mm 1.691 5.548
1/4" 0.076 0.249 5" 30.461 99.940 1-1/8" 1.534 5.033
8mm 0.120 0.398 6-1/2" 51.093 167.630 32mm 1.894 6.314
5/16" 0.118 0.387 6" 43.860 143.900 1-1/4" 1.924 6.349
3/8" 0.170 0.557 7-1/2" 68.226 225.000 35mm 2.390 7.553
9mm 0.152 0.498 7" 59.432 196.000 1-3/8" 2.303 7.550
11mm 0.228 0.748 10" 121.048 397.140 38mm 2.792 8.903
10mm 0.189 0.620 8" 77.586 254.55 36mm 2.438 7.999
12mm 0.271 0.889 40mm 3.009 9.872
7/16" 0.232 0.761 1-1/2" 2.715 8.951
13mm 0.318 1.043 1-3/4" 3.712 12.179
1/2" 0.303 0.994 1-5/8" 3.200 10.449
9/16" 0.383 1.256 1-7/8" 4.260 13.977
14mm 0.368 1.207 45mm 3.807 12.555
5/8" 0.473 1.551 50mm 4.698 15.414
15mm 0.424 1.391 48mm 4.330 14.205
17mm 0.543 1.791 2-1/8" 5.475 17.963
16mm 0.481 1.578 2" 4.848 15.906
18mm 0.610 2.001 60mm 6.768 22.205
11/16" 0.573 1.880 2-1/4" 6.135 20.128
3/4" 0.682 2.237 2-3/8" 6.838 22.435
2-1/2" 7.576 24.856
2-5/8" 8.354 27.409
2-3/4" 9.169 30.083
Hastelloy steel bar weight calculation formula

The following methods can be applied to figure out the weight of a round bar:

Method 1: Weight = R2 / 40.5

Where:
OD: Outer diameter (unit: mm)
R : Radius (R = OD/2) (unit: mm)

Method 2: Weight = OD2 x 0.00617

Where:
OD : Outer diameter (unit: mm)

Method 3: Weight = R2 x 0.02466

Where:
OD: Outer diameter (unit: mm)
R: Radius (R = OD/2) (unit: mm)

Method 4: Weight = OD2/ 162

Where:
OD: Outer diameter (unit: mm)

Method 5: Weight = 0.0007854 x OD x OD x 7.85

Where:
OD : Outer diameter (unit: mm)

Standards Hastelloy steel round bar
  • Hastelloy C22: DIN 17752, ASTM B574, ISO 9724, ISO 9723, DIN 17753
  • Hastelloy C276: ISO 9723, ASTM B574, DIN 17752, ISO 9724, DIN 17754, DIN 17753, VdTüV 400/12.98
  • Hastelloy B2 : ASME SB-335 , UNS N10665
  • Hastelloy X: AMS 5754, ASME SB-572, WERKSTOFF Nr. 2.4665, AMS 5798, UNS N06002
Hastelloy alloy rod temperature limit
Grade Temprature
Hastelloy C276  up to 1200°F (650°C)
Hastelloy C22  more than 1250° F
Value added services for Hastelloy flat bar offered by Regent

Value added services for Hastelloy flat bar offered by Regent

ASTM B574 Hastelloy bright bar Length
  • Metric system: 9 to 12 metres standard length
  • USA : 40 feet
Hastelloy bar stock
Alloy Diameter in mm Round bar form Weight in kg/m
Hastelloy Alloy 12.7 solution annealed, hot rolled 1.13
8.0 ground, solution annealed, polished 0.44
6.0 cold drawn, pickled, soft annealed 0.25
12.0 ground, hot finished, solution annealed 1.01
20.0 solution annealed, peeled 2.85
16.0 hot finished, solution annealed 1.8
30.0 hot worked, solution annealed, peeled 6.1
25.4 hot finished, solution annealed, peeled 4.5
35.0 Machined, Solution annealed 7.95
31.8 solution annealed, hot rolled 7.05
45.0 hot worked, solution annealed, peeled 14.15
40.0 solution annealed, hot rolled, machined 11.3
55.0 hot rolled, sol annealed, machined 21.0
50.8 annealed, peeled 18.0
63.5 hot finished, solution annealed, peeled 28.0
60.0 hot finished, solution annealed, peeled 26.0
80.0 hot finished, solution annealed, peeled 45.2
70.0 hot worked, solution annealed, peeled 35.0
90.0 peeled, sol annealed 57.3
88.9 hot finished, solution annealed, peeled 57.0
105.0 Round; hot finished, peeled 73.3
101.6 forged, peeled, annealed 70.9
130.0 forged, annealed, peeled 118
115.0 Round; solution annealed, peeled 92.3
180.0 forged, solution annealed, turned 226.2
160.0 forged, solution annealed, turned 180
230.0 forged, solution annealed, turned 369.4
203.2 forged, turned 288
250.0 solution annealed, hot rolled, turned 436.4
Physical properties of Hastelloy alloy square bar
  • Density: 8.89 g/cm3
  • Excellent corrosion resistance
  • Melting Range: 1323-13710C
  • Good weldability
