India's Largest Stockist and Supplier Of Nickel Alloys Since 2007

Nickel Alloy Flanges Manufacturer in India

Nickel Alloy Flanges Accentuate
Ex.Stock
  • NPS:1/2 - 48"
  • Pressure Class: 150 - 2500 LBS
  • Schedule: Sch 5 - XXS
Connection Welding
Type Casting or Forging
Custom Size Yes
Free Sample Yes
Process Forging, Machining, Heating Treatment
Sealing Surface RF, FF, FM, RTJ, T, M, G etc.
State Solid Solution
MTC EN 10204 3.1 and 3.2
HS Code 75089090
Delivery Time
  • Netherlands : 60 Days
  • Malaysia: 7 Days

To Request Urgent Call BackClick Here



Nickel Alloy Flanges Specification



Gasco Approved Pure Nickel 200 Flanges Supplier in Mumbai As Per ASME B16.5

Equivalent Standards of ASTM B564 UNS N02201 Plate Flange
Grades UNS Werkstoff NR. GOST JIS BS EN AFNOR
201 N02201 2.4068 НП-2 NW 2201 NA 12 LC-Ni 99 -
200 N02200 2.4066 NW 2200 NA 11 Ni 99.2 N-100M



Pure Nickel 200 Slip On Flange

Pure Nickel 200 Slip On Flange

Nickel 201 Blind Flanges

Nickel 201 Blind Flanges

UNS N02200 Weld Neck Flange

UNS N02200 Weld Neck Flange

Table of content
Regent Steel & Engineering Co.
Nickel Alloy Flanges Specification
Sizes
Pure Nickel 200 Slip On Flange Sizes
  • NPS: 1/2 to 48"
  • SCH: Sch 5 to XXS
  • Custom
Pressure Class
Nickel 201 Blind Flanges Pressure Class
  • 2500
  • 900, 600
  • 1500 LBS
  • 300, 150
Manufacturing Standards
UNS N02200 Weld Neck Flange Manufacturing Standards
  • ASME B16.5
  • MSS SP44
  • ASME B16.47 Series A & B
Trade Name
Ni 200 Lap Joint Flanges Benefits
  • Mechanical Strength
  • Resistance to Corrosion
  • Longevity
  • Higher Temperature Tolerance
Types
Types Of Alloy 200 Threaded Flange
  • Blind
  • Weld Neck
  • Slip On
  • Socket Weld
Process
ASTM B564 UNS N02201 Plate Flange Process
  • Forging
  • Cutting
  • Rolling
Meet Requirement
Pure Nickel 201 Socket Weld Flange Meet Requirement
  • NACE MR0175
  • ISO 15156
  • NACE MR0103
  • Sour service
Standards
Alloy 201 Orifice Flanges Standards
  • ASTM B564 | ASME SB 564
  • WNR: 2.4066
  • UNS: N02200
Origin
UNS N02200 Weld Neck Flange Origin
  • European
  • Janpanese
  • American
  • Russia
  • Korean
Finish
Ni 201 Spectacle Blind Flanges Finish
  • Spiral, Smooth
  • Mirror
  • Serrated, Concentric
Marking
Nickel 201 Blind Flanges Marking
  • Sizes
  • Pressure class
  • Face type
  • ASTM/ ASME standard
  • Origin of material
Threads
WNR 2.4068 Spacer Flange Threads
  • NPT, FNPT
  • BSPP, MNPT
  • BSPT etc.
Packaging
Pure Nickel 200 Slip On Flange Packaging
  • Plywood Case
  • Paper Box
  • Pallet
  • Wooden Box
  • Custom
Properties
NW 2200 Expander Flange Properties
  • Melting Point: 2615°F - 2635°F (1435°C - 1446°C)
  • Temp.: 705°C - 925°C (1300°F - 1700°F)
  • Density: 8.9gm/cm³
Testing
ASTM B564 UNS N02200 Ring Type Joint Flange Testing
  • Hardness
  • Tensile
  • Pressure
  • PMI test

Keep Bulk Stock of Alloy 201 Slip On and Blind Flanges Produced With High Quality Raw Materials

Most Common Types Of Nickel Alloy Flanges
Pure Nickel 201 Socket Weld Flange

Pure Nickel 201 Socket Weld Flange

Alloy 200 Threaded Flange

Alloy 200 Threaded Flange

ASTM B564 UNS N02201 Plate Flange

ASTM B564 UNS N02201 Plate Flange

Ni 200 Lap Joint Flanges

Ni 200 Lap Joint Flanges

Alloy 201 Orifice Flanges

Alloy 201 Orifice Flanges

ASTM B564 UNS N02200 Ring Type Joint Flange

ASTM B564 UNS N02200 Ring Type Joint Flange

Ni 201 Spectacle Blind Flanges

Ni 201 Spectacle Blind Flanges

NW 2200 Expander Flange

NW 2200 Expander Flange

WNR 2.4068 Spacer Flange

WNR 2.4068 Spacer Flange


What Are the Documentation Required for Nickel Alloy Flanges ?
  • Certification of Raw Materials
  • Manufacturer Testing Certificate
  • Inspection Report of Third Party
  • 100% Radiography Report

Get Smooth and Mirror Finish ASTM B564 UNS N02200 Weld Neck Flange in Different Sizes and Schedules

Pure Nickel 200 Slip On Flange Surface Finishes
Pure Nickel 200 Slip On Flange Surface Finishes

Size Chart of Nickel 201 Blind Flanges
Nominal Sizes Outside Diameter (O.D.) Diameter of Hub at Base Diameter of Raised Face Thickness Length Thru Hub Radius of Fillet Diameter of Hub at Bevel Diameter or Bore Depth of Socket
Lap Joint Slip-On Threaded Socket Welding Neck Lap Joint Slip-on Socket
O X R Q Y Y Y r H B W Z
1/2" 3-1/2 1-3/16 1-3/8 7/16 5/8 5/8 1-7/8 1/8 .84 .90 .88 3/8
1" 4-1/4 1-15/16 2 9/16 11/16 11/16 2-3/16 1/8 1.32 1.38 1.36 1/2
1-1/2" 5 2-9/16 2-7/8 11/16 7/8 7/8 2-7/16 1/4 1.90 1.97 1.95 5/8
2-1/2" 7 3-9/16 4-1/8 7/8 1-1/8 1-1/8 2-3/4 5/16 2.88 2.97 2.94 3/4
3-1/2" 8-1/2 4-13/16 5-1/2 15/16 1-1/4 1-1/4 2-13/16 3/8 4.00 4.10 4.07 7/8
5" 10 6-7/16 7.5/16 15/16 1-7/16 1-7/16 3-1/2 7/16 5.56 5.69 5.66 15/16
8" 13-1/2 9-11/16 10-5/8 1-1/8 1-3/4 1-3/4 4 1/2 8.63 8.75 8.72 1-1/4
12" 19 14-3/8 15 1-1/4 2-3/16 2-3/16 4-1/2 1/2 12.75 12.92 12.88 1-9/16
16" 23-1/2 18 18-1/2 1-7/16 3-7/16 2-1/2 5 1/2 16.00 16.19 16.16 1-3/4
20" 27-1/2 22 23 1-11/16 4-1/16 2-7/8 5-11/16 1/2 20.00 20.25 20.20 2-1/8
6" 11 7-9/16 8-1/2 1 1-9/16 1-9/16 3-1/2 1/2 6.63 6.75 6.72 1-1/16
1-1/4" 4-5/8 2-5/16 2-1/2 5/8 13/16 13/16 2-1/4 3/16 1.66 1.72 1.70 9/16
18" 25 19-7/8 21 1-9/16 3-13/16 2-11/16 5-1/2 1/2 18.00 18.20 18.18 1-15/16
10" 16 12 12-3/4 1-3/16 1-15/16 1-15/16 4 1/2 10.75 10.92 10.88 1-5/16
3/4" 3-7/8 1-1/2 1-11/16 1/2 5/8 5/8 2-1/16 1/8 1.05 1.11 1.09 7/16
2" 6 3-1/16 3-5/8 3/4 1 1 2-1/2 5/16 2.38 2.46 2.44 11/16
3" 7-1/2 4-1/4 5 15/16 1-3/16 1-3/16 2-3/4 3/8 3.50 3.60 3.57 13/16
4" 9 5-5/16 6-3/16 15/16 1-5/16 1-5/16 3 7/16 4.50 4.60 4.57 15/16
14" 21 15-3/4 16-1/4 1-3/8 3-1/8 2-1/4 5 1/2 14.00 14.18 14.14 1-5/8
24" 32 26-1/8 27-1/4 1-7/8 4-3/8 3-1/4 6 1/2 24.00 24.25 24.25 2-1/2
UNS N02200 Weld Neck Flange Schedules Chart
Nominal Sizes Outside Diameter (O.D.) SCH 10 SCH 30 SCH 140 SCH 120 SCH 40 EXT Hvy SCH 100 SCH 160 SCH 20 STD Wall SCH 60 SCH 80 XX Hvy
½" 0.84 0.083 - - - 0.109 0.147 - 0.188 - 0.109 - 0.147 0.294
1" 1.315 0.109 - - - 0.133 0.179 - 0.25 - 0.133 - 0.179 0.358
1 ½" 1.9 0.109 - - - 0.145 0.2 - 0.281 - 0.145 - 0.2 0.4
2 ½" 2.875 0.12 - - - 0.203 0.276 - 0.375 - 0.203 - 0.276 0.552
3 ½" 4 0.12 - - - 0.226 0.318 - - - 0.226 - 0.318 0.636
5" 5.563 0.134 - - 0.5 0.258 0.375 - 0.625 - 0.258 - 0.375 0.75
8" 8.625 0.148 0.277 0.812 0.719 0.322 0.5 0.594 0.906 0.25 0.322 0.406 0.5 0.875
12" 12.75 0.18 0.33 1.125 1 0.406 0.5 0.844 1.312 0.25 0.375 0.562 0.688 1
16" 16 0.25 0.375 1.438 1.219 0.5 0.5 1.031 1.594 0.312 0.375 0.656 0.844 -
20" 20 0.25 0.5 1.75 1.5 0.594 0.5 1.281 1.969 0.375 0.375 0.812 1.031 -
¾" 1.05 0.083 - - - 0.113 0.154 - 0.219 - 0.113 - 0.154 0.308
1 ¼" 1.66 0.109 - - - 0.14 0.191 - 0.25 - 0.14 - 0.191 0.382
2" 2.375 0.109 - - - 0.154 0.218 - 0.344 - 0.154 - 0.218 0.436
3" 3.5 0.12 - - - 0.216 0.3 - 0.438 - 0.216 - 0.3 0.6
4" 4.5 0.12 - - 0.438 0.237 0.337 - 0.531 - 0.237 - 0.337 0.674
14" 14 0.25 0.375 1.25 1.094 0.438 0.5 0.938 1.406 0.312 0.375 0.594 0.75 -
18" 18 0.25 0.438 1.562 1.375 0.562 0.5 1.156 1.781 0.312 0.375 0.75 0.938 -
6" 6.625 0.134 - - 0.562 0.28 0.432 - 0.719 - 0.28 - 0.432 0.864
10" 10.75 0.165 0.307 1 0.844 0.365 0.5 0.719 1.125 0.25 0.365 0.5 0.594 1
22" 22 0.25 - - - - 0.5 - - - 0.375 - - -
24" 24 0.25 0.562 2.062 1.812 0.688 0.5 1.531 2.344 0.375 0.375 0.969 1.219 -
How Do You Properly Maintain Nickel Alloy Flanges to Ensure Longevity?
Maintain Nickel Alloy Flanges

Ready Stock of PMI and Hardness Tested Ni 201 Socket Weld Flange With Accurate Drill Holes for Easy Installation
201 Socket Weld Pure Nickel Flange Tested Method
  • PMI Testing
  • Pressure Test Report
  • Tensile
  • Hardness Report

Buy Werkstoff NR. 2.4066 Threaded Flanges Online With Pressure Class 150 to 2500 For Condensers and Heat Exchangers
Pressure Rating of Alloy 200 Threaded Flange
Temperature In °F Pressure Rating Classes
300 600 1500 150 400 900 2500
-20 - 100 720 1440 3600 275 960 2160 6000
300 540 1080 2700 205 720 1620 4500
500 465 930 2330 170 620 1395 3880
650 430 860 2150 125 575 1290 3580
750 415 830 2075 95 555 1245 3460
850 395 790 1980 65 530 1190 3300
950 380 765 1910 35 510 1145 3180
1050 310 615 1545 20 410 925 2570
1150 200 400 995 20 265 595 1655
1250 115 225 565 20 150 340 945
1350 60 125 310 20 80 185 515
1450 35 70 170 15 45 105 285
200 600 1200 3000 230 800 1800 5000
1000 320 640 1605 20 430 965 2675
1100 255 515 1285 20 345 770 2145
400 495 995 2485 190 660 1490 4140
1200 155 310 770 20 205 465 1285
600 435 875 2185 140 580 1310 3640
1300 85 170 430 20 115 255 715
1400 50 95 240 20 65 145 400
700 425 850 2125 110 565 1275 3540
900 390 780 1945 50 520 1165 3240
800 405 805 2015 80 540 1210 3360
1500 25 55 135 10 35 80 230
Nickel 200 Flanges Price List
Check the Latest Nickel Alloy Flanges Prices Click Here
Type Of Flanges Size Class SCH Price In USD Per Piece
Blind Flange 3/4" 150 Sch 40 US $ 2.14
1" 150 US $ 4.64
11/2" 150 US $ 6.37
3" 150 US $ 11.30
6" 150 US $ 16.63
Weld Neck Flange 2" 150 SCH STD US $ 4.10
3" 150 US $ 5.58
6" 150 US $ 9.44
10" 150 US $ 14.87
12" 150 US $ 17.82
Slip On Flange 1 /1/2" 150 80 US $ 4.46
3" 150 US $ 7.45
4" 150 US $ 9.58
8" 150 US $ 14.92
Socket Weld Flange 3/4" 300 SCH XS US $ 2.11
1" 300 US $ 3.43
2" 300 US $ 6.12
4" 300 US $ 9.86
6" 300 US $ 11.84
Nickel Alloy Flanges Applications
Nickel Alloy Flanges Applications

Nickel Alloy Flanges Manufacturer in India, Provides Corrosion Resistance & High Strength Which are Ideal.

Ni 200 Lap Joint Flanges Chemical Composition
Grade's Chemical Composition (Max)
Si Mn C Fe Cu S Ni (Min)
201 0.35 0.35 0.02 0.40 0.25 0.01 99
200 0.15
Mechanical Properties of Alloy 201 Orifice Flanges
Grade Density Yield Strength (0.2% Offset) Tensile Strength Melting Point Elongation
Nickel Alloy Flange 201/ 200 8.9 g/cm3 MPa - 148, Psi - 21500 MPa - 462, Psi - 67000 2635°F (1446°C) 45%
Ni 201 Spectacle Blind Flanges Dimension
Nominal Size's Outside Daimeter (O.D.) Inside Diameter (I.D.) Raised Face (R) RF (Raised Face) Raised Face (RF) Thickness (T) Holes Of Bolts (B) T1 H Bolts Holes Numbers BC (Circle Of Bolt) Thickness Of Flat Face (FF) (T2)
1/2" 3.75 0.88 1.38 .063 0.88 0.62 0.50 1.50 4 2.62 0.82
3/4" 4.62 1.09 1.69 .063 1.00 0.75 .056 1.88 4 3.25 0.94
2" 6.50 2.44 3.62 .063 1.31 0.75 0.82 3.31 8 5.00 1.25
2-1/2" 7.50 2.94 4.12 .063 1.50 0.88 0.94 3.94 8 5.88 1.44
3-1/2" 9.00 4.07 5.50 .063 1.75 0.88 1.13 5.25 8 7.25 1.69
5" 11.00 5.66 7.31 .063 2.00 0.88 1.32 7.00 8 9.25 1.94
6" 12.50 6.72 8.50 .063 2.06 0.88 1.38 8.12 12 10.62 2.00
10" 17.50 10.88 12.75 .063 2.62 1.12 1.82 12.62 16 15.25 2.56
14" 23.00 14.14 16.25 .063 3.00 1.25 2.06 16.75 20 20.25 2.94
16" 25.50 16.16 18.50 .063 3.25 1.38 2.19 19.00 20 22.50 3.19
1" 4.88 1.36 2.00 .063 1.06 0.75 0.63 2.12 4 3.50 1.00
3" 8.25 3.57 5.00 .063 1.69 0.88 1.06 4.62 8 6.62 1.63
12" 20.50 12.88 15.00 .063 2.88 1.25 1.94 14.75 16 17.75 2.82
4" 10.00 4.57 6.19 .063 1.88 0.88 1.19 5.75 8 7.88 1.82
1-1/2" 6.12 1.95 2.88 .063 1.19 0.88 0.75 2.75 4 4.50 1.13
1-1/4" 5.25 1.70 2.50 .063 1.06 0.75 0.69 2.50 4 3.88 1.00
18" 28.00 18.18 21.00 .063 3.50 1.38 2.32 21.00 24 24.75 3.44
20" 30.50 20.20 23.00 .063 3.75 1.38 2.44 23.12 24 27.00 3.69
8" 15.00 8.72 10.62 .063 2.44 1.00 1.56 10.25 12 13.00 2.38
22" 33.00 22.22 25.25 .063 4.00 1.63 2.57 25.25 24 29.25 3.94
24" 36.00 24.25 27.25 .063 4.19 1.62 2.69 27.62 24 32.00 4.13
What are the Steps to Choosing the Right Grade?
  • Ensuring the Compatibility with Transported Fluid
  • By Checking the Budget with Performance Needs.
  • Assessing Chemical Exposure, Pressure, and Temperature.
Which are the Major Advantages of Using Nickel Alloy Flanges ?
Advantages of Using Nickel Alloy Flanges


Nickel Alloy Flanges Manufacturer in India, Provide Higher Performance Flanges Which are Specially Designed for Withstand Higher Temperature Environments

Weight Chart of NW 2200 Expander Flange
Nominal Sizes Outside Diameter (O.D.) Diameter of Raised Face Flange Thickness (min) Diam. of Hub Number of Bolts Length Hub.Y Diam. of Bolt Circle Thread Length Diam. of Bolt Holes Diam. of Bolts (inch) LB KG
Inch Diameter O G C X BN Y BC T BH BD
1/2" 15 89.00 35.10 11.20 30.20 4 15.70 60.50 15.70 15.80 1/2" 0.9 0.4
1" 25 108.00 50.80 14.20 49.30 4 17.50 79.30 17.50 15.80 1/2" 1.8 0.8
1-1/2" 40 127.00 73.20 17.50 65.00 4 22.40 98.60 22.40 15.80 1/2" 3.3 1.5
2-1/2" 65 178.00 104.60 22.40 90.40 4 28.40 139.70 28.40 19.10 5/8" 8.1 3.7
3-1/2" 90 216.00 139.70 23.90 122.20 8 31.80 177.80 31.80 19.10 5/8" 11.2 5.1
5" 125 254.00 185.70 23.90 163.60 8 36.60 215.90 36.60 22.40 3/4" 15.4 7
18" 450 635.00 533.40 39.60 505.00 16 68.30 577.90 68.30 31.80 1 1/8" 126 57
8" 200 343.00 269.70 28.40 246.10 8 44.50 298.50 44.50 22.40 3/4" 28.6 13
12" 300 482.50 381.00 31.80 365.30 12 55.60 431.80 55.60 25.40 7/8" 64 29
16" 400 597.00 469.90 36.60 457.20 16 63.50 539.80 63.50 28.50 1" 103 47
20" 500 698.50 584.20 42.90 558.80 20 73.20 635.00 73.20 31.80 1 1/8" 167 76
3/4" 20 98.50 42.90 12.70 38.10 4 15.70 69.90 15.70 15.80 1/2" 1.5 0.7
4" 100 228.50 157.20 23.90 134.90 8 33.30 190.50 33.30 19.10 5/8" 13 5.9
6" 150 279.50 215.90 25.40 192.00 8 39.60 241.30 39.60 22.40 3/4" 18.5 8.4
10" 250 406.50 323.90 30.20 304.80 12 49.30 362.00 49.30 25.40 7/8" 39.5 18
2" 50 152.50 91.90 19.10 77.70 4 25.40 120.70 25.40 19.10 5/8" 5.1 2.3
14" 350 533.50 412.80 35.10 400.10 12 57.20 476.30 57.20 28.50 1" 86 39
1-1/4" 32 117.50 63.50 15.70 58.70 4 20.60 88.90 20.60 15.80 1/2" 2.6 1.2
3" 80 190.50 127.00 23.90 108.00 4 30.20 152.40 30.20 19.10 5/8" 9 4.1
24" 600 813.00 692.20 47.80 663.40 20 82.60 749.30 82.60 35.10 1 1/4" 214 97
Nickel Alloy Flanges Delivery Time As Per Location
Cost Changes
5 % extra
Export to Delivery Time
Saudi Arabia 7
France 30
Qatar 7
Kuwait 10
South Africa 25-30
USA 40-60
Bahrain 9
Philippines 14
Oman 5
UAE 5 days
Italy 30
Malaysia 10
Uk 30
Regent Steel

Why Should You Buy From Regent Steel ?

  • Distributor of Renowned Mills of Nickel Alloys in Europe and USA
  • Experience of 2 Decades as a Supplier of High Temperature Alloys in Dubai ( UAE), Saudi Arabia and Africa.
  • Largest Stockist of Nickel Alloy Flat Products in Mumbai
  • Ready Stock of Sheets, Coils, Strips and Bars in Over 50 Sizes at Al Jubail, Abu Dhabi, Muscat and South Africa
  • Facility of Cut to Size at No Extra Cost.
  • Weekly Delivery to Nigeria, Qatar, Dammam, Sharjah and Singapore
  • NACE Certified Material at Dealer Price.
  • Resale Price for Traders, Wholesalers, Importers and Stockholders in Mena Countries
  • Data Sheets and MTC Along With Quote.
  • Free Sample, Latest Price List on Request
  • Renowned Supplier in Heat Exchangers, Instrumentation, and Oil and Gas Industry
  • Compare Weight Chart and Price Per Kg in China and India.

Nickel 200 Products

Check Our Product Range

Get in touch

Call

+91-22-6639 4858

Email

export@regentsteel.com

close

© Copyright Regent Steel & Engg.Co. 2026. All Right Reserved.
